Veterinary drug residue rapid detector

Product use:

This veterinary drug residue detector is suitable for on-site rapid screening and quantitative detection of veterinary drug residues in livestock and poultry meat products such as pigs, chickens, ducks, sheep, cattle, and milk, including antibiotic residues, clenbuterol hormone residues, and toxic and harmful substances in aquatic products.

This veterinary drug residue detector is an integrated meat safety rapid detection and analysis equipment, which can be widely used in animal husbandry farms, slaughterhouses, food and meat product deep processing enterprises, food and drug administration, inspection and quarantine departments, health departments, colleges and universities, scientific research institutes, agricultural departments and other units.

Test items:

Clenbuterol hormones (veterinary drugs): clenbuterol hydrochloride, salbutamol, ractopamine, diethylstilbestrol, olaquinol, etc.

Antibiotic residues (veterinary drugs): tetracyclines, nitrofurans, sulfonamides, floxacins, quinolones, gentamicin, streptomycin, amoxicillin, erythromycin, etc.

Aquatic product safety: malachite green, chloramphenicol, nitrofurantoin metabolism, nitrofurazone metabolism, furaltadone metabolism, furazolidone metabolism, etc.

And extended detection of diseased meat and meat freshness.

Product performance:

1. Android smart operating system, using a more efficient UI interactive interface, the instrument has wifi network upload, 4G network transmission, GPRS wireless remote transmission, network cable connection functions, fast batch upload of data.

2. High degree of intelligence, the instrument has self-test function: it has power-on self-test and zero adjustment functions, and has automatic detection repeatability function.

3. A new generation of high-speed thermal printer, which can automatically print the test report and QR code after the test is completed.

4. The instrument is equipped with a supervision platform, data can be uploaded to the local area network and the Internet, and the test results are directly transmitted to the food safety supervision platform. Carry out regional food safety supervision and big data analysis and processing and data statistics, detect the long-term and short-term dynamics of regional food safety, and achieve food safety problem estimation and early warning

5. Integrated host, including food safety detection module, multi-channel pesticide residue detection module, colloidal gold immunochromatography detection module.

6. Integrated portable rapid detection equipment, which meets the needs of on-site and mobile detection, can realize the detection of all detection items under the same software, and can intuitively display the test results through the same window.

7. Colloidal gold module detection method: track-type automatic transmission scanning, and the test card is automatically exited after the test is completed.

8. The instrument has a built-in camera to take pictures, which can display the real-time image of the gold label card. The system automatically analyzes and presents the CT curve graph, and the CT line is automatically identified without manual adjustment.

9. The instrument has a multi-category sample menu library, which can flexibly select the test sample, and different detection channels can detect different sample items at the same time.

10. The instrument has a built-in operation teaching video. Click the video module to quickly view it, which is convenient for users to use.

11. Sample processing is simple and labor-saving, and the overall operation is fast, safe and convenient.

12. The instrument can be configured with an identity recognition function, which can be turned on by a password or by swiping an ID card to prevent non-staff operations, etc.

13. High sensitivity, high detection accuracy, high repeatability accuracy, scanning high-precision optical sensor.

14. Built-in powerful database, you can directly select sample name, detection indicators, inspection unit and other information on the instrument, or directly edit and enter sample name, detection indicators, inspection unit and other information on the instrument and save them in the sample database.

15. The instrument has the functions of recalibration, locking, and restoring factory settings.

16. The result judgment line can be modified, the reference value calibration value can be saved, and the data will not be lost when the power is off.

17. Compatible with all colloidal gold cards on the market, the use of consumables is not restricted, and the user experience is greatly enhanced.

Main parameters:

1. The main control chip uses ARM Cortex-A7, RK3288/4 core processor, the main frequency is 1.88Ghz, the operation speed is faster and the stability is stronger.

2. Display mode: 7-inch LCD touch screen display, humanized Chinese operation interface, intuitive and simple reading.

3. AC and DC dual-purpose, DC 12V power supply, can be connected to the vehicle power supply, can be equipped with 6ah large-capacity rechargeable lithium battery, convenient for outdoor flow testing.

4. Four-wavelength cold light source, each channel is equipped with 410, 520, 590, 630nm wavelength light source, standard advanced optical path switching device, patented optical path switching function can achieve up to 64 wavelengths, and all detection items can achieve all channels at the same time.

5. Automatic adjustment and calibration of light source brightness

6. Intelligent constant current voltage regulation, automatic calibration of light intensity, long-term continuous working light source without temperature drift phenomenon.

7. Built-in new national limit standards, on-site comparison with the measured results, and continuous update of standards.

8. Uninterrupted sampling, continuous detection

9. Automatic accumulation of sample numbers.

10. Wireless data upload platform, and can be exported from the platform as Excel tables.

11. Storage capacity of 200,000 test results

12. Supports USB flash drive copying, standard USB interface, no need to plug and unplug drivers.

13. Test items can be expanded, firmware can be upgraded

14. Instrument size: 43×35×20cm, main unit net weight: 5.2kg

★Manufacturers must have food safety testing intellectual property management system certification

★Manufacturers have high-tech enterprise certification

★Instruments have food safety transfer copyrights

★Instruments have metrology reports issued by national metrology institutes

★Reagents have reagent test reports issued by national metrology institutes

★With ISO9001 quality management system certification

★Manufacturers must have independent trademark intellectual property rights
