Enzyme-linked immunosorbent assay analyzer

Product features

*10.4-inch color LCD touch screen input, large screen display, fast operation;

*Full screen display of 96 hole visual cloth board operation interface;

Automatically store standard curves, users can make corrections to the standard curves;

Built in embedded system, can operate, store, and print without the need for an external computer;

Automatic zero adjustment can be performed in both single wavelength and dual wavelength testing modes;

Optional external PC software, networked support, catering to the direction of digital development, customizable upload;

*Massive existence, capable of storing at least 1 million board (96) test data and 500 programming projects, and supporting data backup, recovery, and merging;

*24 different items can be tested on the same board and can be distinguished by display, and qualitative and quantitative items can be tested on the same board;

*Template function, fixed detection work, greatly simplifying the workload of operators;

Intelligent calculation of test results to ensure accuracy and effectiveness, and automatic alarm capability;

New Windows color graphical interface, all Chinese operating system, supporting mouse and keyboard, and supporting multiple input methods;

Intelligent light source switch, extending its lifespan;

*Comprehensive and comprehensive quality control functions, including Westguard multi rule quality control, instant method quality control, and various quality control charts and parameter calculations, with quality control alarm function;

Provide multiple printing methods and various forms of Chinese reports, and customize various types of reports;

*Layout and save import functions greatly improve the testing efficiency of commonly used projects;

*Optional calculation methods include absorbance, Cut Off qualitative calculation, single point calibration, line regression, linear regression, exponential regression, logarithmic regression, double logarithmic regression, log log log, power regression, four parameter regression, enzyme inhibition rate, etc;

A dedicated system maintenance menu that automatically determines the current status and performance indicators of the instrument, and can print relevant data;

Technical parameter

Wavelength range: 330-1100nm

*Filter configuration: 10 filter positions, standard with 405nm, 450nm, 492nm, 630nm, optional with 6 custom wavelengths

Absorbance range: 0.000-4.000A

*Number of optical channels: 8 channels for optical path detection, with an additional independent reference channel

*Indicator stability: ≤ ± 0.002A or ≤ 0.5% T/10min

*Indication error (accuracy): ≤ ± 0.005A or ± 0.2% T

*Repeatability: ≤ 0.2% or ≤ 0.2% T

Sensitivity: ≥ 0.01 (L/mg)

Channel difference: ≤ 0.01A

Wavelength indication error: ± 1nm

Half width: ≤ 8nm

Peak transmittance: ≥ 35%

Resolution: 0.001A (display), 0.0001A (internal calculation)

*Reading speed: single wavelength ≤ 3 seconds/96 holes, dual wavelength ≤ 6 seconds/96 holes

Vibration plate function: adjustable speed and time

Light source type: halogen tungsten lamp

Flat noodles type: standard 96 well or other types of enzyme standard plate and strip

Applicable hole types: flat bottomed, U-shaped, and V-shaped

*Display method: 10.4-inch color LCD display screen

Input method: Touch screen input, optional mouse and keyboard

Printing: Built in thermal printer, can be connected to an external printer

Interface: DVI port, VGA port, Ethernet port, USB port, audio port, RS232 serial port

Operating environment: temperature between 5-40 ℃; Humidity 15% -80%

Power supply voltage: 220V ± 10%, 50/60Hz

Volume: 470mm x 350mm x 210mm (length x width x height)

Weight: 11.5Kg
