HM-YN1 Kinematic Viscosity Tester

Product Introduction

The HM-YN1 is a kinematic viscosity tester for laboratories measuring Newtonian liquid petroleum products and other liquid samples with a capillary method. It supports Penske and Ubbelohde testing in one instrument, so a laboratory can select the method that matches its established procedure. A 7-inch industrial color touchscreen presents the operating controls, while the German A-grade Pt100 stainless steel probe and built-in temperature calibration support controlled measurement conditions. The electric heating unit reaches a maximum power of 1600 W, and stirring speed can be adjusted from 60% to 100%. Results can be stored for later review, with capacity for 10,000 test results. The HM-YN1 suits petroleum, chemical, pharmaceutical, food, printing, textile, cosmetics and research laboratories that need a general-purpose bench instrument. For model-specific workflow notes, open the HM-YN1 product reference before configuring capillary accessories. It is intended for controlled bench testing where operators need documented model details, repeatable preparation and a clear record of the selected procedure.

Applications / Testing Items

1. Petroleum product kinematic viscosity measurement.
2. Chemical solvent and polymer-solution testing.
3. Pharmaceutical preparations such as ointments and oral liquids.
4. Food, beverage, ink, adhesive, dye and cosmetic sample testing.
5. Basic liquid-property research in laboratories and institutes.

Functional Performance / Features

1. Two capillary test methods are available: Penske and Ubbelohde.
2. 7-inch industrial color touchscreen for direct operation.
3. German A-grade Pt100 stainless steel probe.
4. Built-in temperature calibration supports measurement setup.
5. Electric heating unit with maximum 1600 W power.
6. Stirring speed adjustable from 60% to 100%.
7. Automatic storage capacity for 10,000 test results.
8. Designed for long-term laboratory operation.
9. Instrument dimensions are 530 mm × 310 mm × 232.5 mm.
10. Supports GB/T265, GB/T1841 and SY/T5651 procedures.

Main Parameters

Technical Parameters
