HM-100Y Portable X-ray Machine with 10-Inch Display

Product Introduction

HM-100Y is a portable X-ray machine for inspection teams that benefit from a wider on-instrument image view. The source material describes the platform for internal inspection of industrial products and electronic components, experiments, scientific research, teaching, engineering, archaeology, identification, veterinary environments, field operations, emergency rescue, valuable Chinese herbal medicine foreign-object inspection, and security inspection. The unit uses a CCD high-gain working principle, with the manual describing a 0.5 mA low-dose operation. Real-time imaging lets the operator see the internal condition of the workpiece when the button is pressed. The machine is intended for bright-room operation without a darkroom and can connect to a computer for printing perspective images. Current and voltage adjustment allows image clarity to be tuned for the inspection situation. HM-100Y is differentiated by its 10-inch LCD screen with fixing function, observation thickness up to 320 mm, and 45–90 kV tube high pressure. This configuration is useful when a larger display helps operators review internal structures, compare images, or work with inspection subjects that require a broader viewing area. For a smaller display format, see HM-75Y.

Applications / Testing Items

• Internal inspection of industrial products and assemblies
• Electronic component and circuit-related inspection
• Scientific research, experiments, and teaching demonstrations
• Engineering, archaeology, and identification in mobile settings
• Pet hospitals, veterinary hospitals, breeding grounds, and zoos
• Field operations, emergency rescue, and earthquake rescue
• Foreign-object inspection in valuable Chinese herbal medicine
• Public-security and counter-terrorism inspection

Functional Performance / Features

1. 10-inch LCD screen provides a broad integrated viewing area.
2. Fixing function supports a steady display arrangement during inspection.
3. Observation thickness is specified up to 320 mm for HM-100Y.
4. 45–90 kV tube high pressure is specified for this model.
5. CCD high-gain operation supports the stated low-dose approach.
6. Real-time imaging shows internal conditions directly during operation.
7. Bright-room use avoids the need for a darkroom.
8. Adjustable current and voltage support clarity adjustment for different workpieces.
9. Computer connection supports printing of perspective images.
10. 200 W power dissipation supports efficient routine operation.
11. Portable construction allows the instrument to move between work locations.
12. Simple controls support quick familiarization for operating personnel.

Main Parameters

Technical Parameters

Follow local radiation-safety requirements and the operating precautions in the product manual. Do not open or dismantle the high-voltage instrument yourself.
