Residual chlorine, total chlorine, chlorine dioxide detector

Product Overview:

The portable residual chlorine, total chlorine, and chlorine dioxide detector is manufactured in accordance with HJ 586-2010 and GB/T 5750.11-2023 standards; with rapid color development detection reagents, it can be measured "fast, simple, accurate, and stable". It has a beautiful appearance, a simple operation interface, and an accurate detection system to help users obtain detailed data, and can more accurately and effectively analyze water conditions, prevent in advance, and avoid losses in time.

Application Industry:

Applicable to drinking water, tap water, medical waste water, industrial sewage, river monitoring, swimming pools, water source protection, production monitoring, scientific research experiments, etc.

Instrument Features:

① Android smart system, easier and faster operation;

② Configured with a cloud monitoring platform, the test results can be directly wirelessly transmitted to the platform for long-term and short-term water quality analysis and auxiliary management.

③ Built-in operation process, simple operation, no training required, direct start;

④ Faster detection speed, on-site data reading;

⑥ Portable, small size, light weight, convenient for outdoor detection;

⑦ Small and beautiful appearance, stable operation and maintenance-free, with good cost performance;

⑧ Adopting imported cold light source, stable optical performance, life up to 100,000 hours;

⑨ AC and DC dual-use, built-in rechargeable lithium battery, environmentally friendly and durable, can support continuous indoor and outdoor work.

Parameter indicators:

Residual chlorine: 0.04~3mg/L, 0.2~15mg/L;

Total chlorine: 0.04~3mg/L, 0.2~15mg/L;

Chlorine dioxide: 0.04~5mg/L, 0.2~20mg/L;

Measurement method: photoelectric colorimetry

Repeatability: <0.5%

Stability: <0.5%

Wavelength selection: automatic

Operating system: Android smart operating system

Display screen: 3.5-inch color LCD touch screen

Sensitivity (absorbance): 0.001

Usage environment: temperature 0~50℃, humidity 0~90%

Data storage: more than 80,000 records

Communication: Type-C, WIFI, hotspot, Bluetooth

Battery: 5600mAh lithium battery

Continuous working time: 8 hours

Power supply voltage: 5V/DC DC

Dimensions: 190*77*72mm

Host weight: 325g

Supported language: Simplified Chinese or English
