HM-WX3B Microbial Limit Tester

Product Introduction

The HM-WX3B from HM Instruments is an entry-level three-channel microbial limit tester designed for laboratories performing routine membrane filtration-based microbial limit testing. Operating on the negative-pressure membrane filtration principle, the instrument captures microorganisms on a filter membrane, which are then cultured and counted to determine microbial content in the sample. The HM-WX3B features straightforward mechanical rotary knob control, allowing each of the three filtration channels to be operated independently. A single built-in diaphragm pump provides reliable vacuum generation with low noise, while the direct drainage design eliminates the need for separate filtrate collection bottles. The L304 stainless steel shell ensures corrosion resistance and easy surface disinfection, supporting cleanroom hygiene requirements. Compatible with disposable Ø47mm filter cups of 100 mL capacity, the HM-WX3B is a practical and cost-effective choice for pharmaceutical water testing, food and beverage quality control, and environmental water monitoring applications.

Applications

• Pharmaceutical water testing — purified water and water for injection microbial limit examination

• Medical device water testing — production water microbial quality verification

• Food and beverage testing — bottled water, beer, juice, and dairy product microbiological analysis

• Disease control water testing — drinking water and HVAC condensate bacterial count monitoring

• Chemical industry — microbial limit testing for process water samples

• Cosmetic microbiological quality testing — water-based formulation microbial enumeration

Key Features

1. Three independent filtration channels with individual mechanical rotary knob control for straightforward operation.

2. Built-in diaphragm pump delivers stable vacuum with low operating noise, eliminating the need for external vacuum sources.

3. Direct drainage design allows filtered liquid to discharge immediately, removing the need for collection bottles.

4. L304 stainless steel shell with brushed finish provides corrosion resistance and facilitates surface disinfection.

5. Compatible with disposable Ø47mm / 100 mL filter cups for single-use convenience and cross-contamination prevention.

6. Filter heads support flame sterilization for rapid decontamination between consecutive test runs.

7. Anti-backflow protection prevents liquid reverse flow, reducing the risk of operational errors affecting test results.

8. Modular filter unit design enables quick disassembly for cleaning, sterilization, and maintenance.

9. Compact 363 x 238 x 202 mm footprint fits standard laboratory bench space and laminar flow cabinets.

10. Lightweight 6.0 kg construction allows easy repositioning and installation.

Main Parameters

Technical Parameters
